Accoseal系列软木橡胶-可靠且应用广泛的密封材料
Accoseal 是一系列市场知名且广泛指定的基于软垫圈技术的密封材料，在汽车密封环境中具有悠久的历史，同时提供具有成本效益的终端产品定制和制造选项。
软木和精选橡胶的独特混合物产生了用于软垫圈密封的材料，由于减少了侧流，允许更大的接触面积和更高的压缩比，从而保证有效的密封屏障，防止潜在的法兰表面缺陷、扭曲和泄漏路径。
材料一致性
在冲压钢或轻质组件中，Accoseal 软木橡胶材料特别有用，能够以较小的紧固件负载和较小的硬件变形进行压缩，从而实现整体优化的系统设计。与其不可压缩的对应物（如橡胶）相反，它的受控侧流允许凹槽组装而无需余量（无挤出现象）。
耐化学性
Accoseal® 产品具有针对汽车应用介质（如燃料、润滑剂和冷却剂）的广泛特性。专用等级是 UL 列出的，如 NC710、NC711 和 NC711G，属于 UL157 燃料类别。尤其是我们的环氧氯丙烷级 NC711G 已经在生物柴油和生物乙醇燃料混合物中进行了广泛的测试，成绩显著。
Accoseal 材料型号及性能参数如下：
|
Product
|
Format
|
Compressibility (%)
400psi / 28 Kg/cm2
|
Characteristics and Uses
|
Certifications
|
|
DC100
|
Sheets / Rolls
|
25 - 45
|
General-purpose gasket and sealing material; high cork content, minimum side flow.
|
|
|
DC179
|
Sheets
|
35-50
|
Highly compressible material for low bolting pressures
|
|
|
DC205
|
Sheets / Rolls
|
15 -30 / 25-45
|
Economical, highly compressible material for low bolting pressures.
|
|
|
LC800
|
Sheets
|
10 -30
|
Outstanding flexibility and resilience over wide range of temperatures. Excellent for coolant use.
|
|
|
NC709
|
Sheets
|
30 - 50
|
Soft, highly compressible for low bolting pressures; oil and solvent resistance.
|
|
|
NC710
|
Sheets / Rolls
|
75 / 70
|
Medium compressibility, with maximum oil and solvent resistance
|
UL listed
|
|
NC711
|
Sheets / Rolls
|
10 - 25 / 15 - 30
|
Low compressibility, with maximum resistance to oils and solvents
|
UL listed
|
|
NC733
|
Sheets
|
10 - 30
|
Performs in a wide range of wet or dry friction applications, operating successfully on jobs ranging from printer drives to heavy-duty transmissions in tractors and road graders.
|
|
|
NL76
|
Sheets
|
30 - 45 @7kg/cm2
|
Highly compressible, resists fatigue; for cushion pads,low sealing stress requirements.
|
|
|
NC711G
|
Rolls
|
15 - 30
|
High quality, low compressibility with excellent chemical resistance to all fuel types UL listed
|
UL listed
|
